New Mexico

Project Services

• Scope Development
• Home office engineering
• Design & procurement
• Laser Scanning

Project Summary

For a fast-paced project, the client required engineering and design services to support the completion of the OSBL areas at a Renewable Diesel Unit (RDU) grassroots facility.

Each area was in varying degrees of completion and required completion as an IFC construction package.

The construction packages were individually prioritized according to construction needs. Areas included Charge Tanks, pumps, pipe bridges over existing roads, piperacks connecting to the  RDU, and the integration of a cooling tower.

Project Highlight Features Include:

• Foundations
• Structural steel add-ons and new steel
• Pipe racks
• Modularized pipe bridges to reduce schedule time
• Piping isometrics
• Cable schedules for power, controls, and lighting
• Grounding plan drawings and details
• Specification for transformers, lighting, and panel boards
• Instrument specification sheets, installation details, and loop drawings
• Material Take-Offs (MTO)
• Request-for-Quotes (RFQ) packages
• Equipment and material bid tabs
• PO documentation for client purchase
